Sintered molybdenum boat for Mo1 99.95% annealing

Sintered molybdenum boat for Mo1 99.95% annealing

Sintered molybdenum boat for Mo1 99.95% annealing
Sintered molybdenum boat for Mo1 99.95% annealingSintered molybdenum boat for Mo1 99.95% annealingSintered molybdenum boat for Mo1 99.95% annealingSintered molybdenum boat for Mo1 99.95% annealingSintered molybdenum boat for Mo1 99.95% annealing
CategoriesMOLYBDENUM BOAT
AlbumView larger image
BrandGETWICK 東吉
ModelMo1,MLa,TZM
Key productcustomized vacuum evaporation molybdenum boat
GradeMo1, TZM, MLa
Working temperature1300-1400 Centigrade
Purity99.95% Min
Density10.2g/cm3
DimensionUser's demand
FeatureHigh temperature resistance
TechniqueWelded
ApplicationIndustry
FOB portShanghai, Guangzhou
Terms of PaymentL/C, D/A, D/P, Western Union, MoneyGram, T/T, Paypal
Update Time2019-04-22
Detail Information

             Sintered molybdenum boat for Mo1 99.95% annealing


Molybdenum Evaporation Boat Introduction:

Molybdenum boats in-process raw material used pure Molybdenum or molybdenum alloy.

They are formed from processed molybdenum plates that have undergone cutting, folding, riveting, welding.

For customer convenience, these molybdenum boats can be shaped to various specifications including square, rectangular, round, trapezoidal, etc.



Product Namecustomized vacuum evaporation molybdenum boat
BrandGETWICK
OriginBaoji, Shaanxi,China
ApearanceMolybdenum Boat
ApplicationHigh temperature furnaces, glass glass melting equipment
Usage Temperature

1300-1400:Mo1

2000:TZM
1700-1900: MLa

SizeOEM drawing Customized size
GradeMo1,TZM, MLa
SurfaceFinish turning, Grinding
PackageWooden cases outside with protective materials inside
MOQ10pc
Delivery time12-15 workdays
MarketGlobal
Condition

1.Sheet ,foil

2.Die stamping/Folding

 We provide mold for the following dimensions:



Name

Symbol of products

Size(mm)

Trough Length  (mm)

volume

 (ccm)

molybdenum boat



Special size can be customized!

DJ210

0.5*75*19

25.5

0.5

DJ211

0.4*49*12

10

0.2

DJ212

0.3*50*13

27

0.5

DJ213

0.1*74*25

50

3.5

DJ214

0.1*47*12

20

6.5

DJ215

0.1*65*12

40

8.9



Molybdenum Boat Applications:

1.Molybdenum can with stand low and high temperatures, which other elements cannot, without being affected.

2..This also makes them highly effective carrying boats in furnace machines.

3.Molybdenum  boats are widely used in  evaporation materials

4. Molybdenum boats are used in the rare earth industry,.nuclear fuel sintering, and capacitor discharged sintering.



Products drawing Show

customized vacuum evaporation molybdenum boat

customized vacuum evaporation molybdenum boat

customized vacuum evaporation molybdenum boat

customized vacuum evaporation molybdenum boat

customized vacuum evaporation molybdenum boat
